BE-200 Low Viscosity
To make use of the merit of Epoxy to the maximum, BE-200 is made for the reinforcement of structure, floating parts(loose parts) and for injection under iron plate. Low viscosity type does not make gaps during injection and it is easy to grout in order to repair the cracks of bridge, dams, columns and slabs. lt contributes to restore the strength of concrete because its physical strength is strong and adhesive strength, anti - corrosive and anti - rust effect is excellent.
※ Uses
● For reinforcement for iron - plate and H-beam.
● Injection to mechanical loading parts.
● Filling up floating parts of the bottom.
● Injection to fine cracks
※ Characteristics
● Automatic injector and micro capsule method can be easily used.
● Mechanical strength is excellent
● Low viscosity type does not generate openings during injection.
● Little hardening contraction
※ Quality
항 목
|
BE - 200 | |
Main |
Hardener | |
Main Ingredients |
Epoxy Resin |
Poly amid amin |
Outlook |
Transparency |
Yellowish brown |
viscosity |
270cps |
50cps |
Pot Life |
50min ±10min(25℃) | |
Theoretical Amount Required |
0.25 ± 0.1kg | |
Complete Curing Time |
24~36hours (25℃) | |
Mixing Ratio |
2 |
1 |
packing |
10kg |
5kg |
![]() |
![]() |
![]() |
![]() |
![]() |
|||
---|---|---|---|---|---|---|---|
